Fixed Scissor Aerial Work Platform

Fixed scissor lift platform, also known as scissor lift platform, belongs to the fixed lift platform.It is mainly according to the user requirements design and manufacture, most installed in the pit, stacked fall state and the ground level, convenient for walking does not obstruct traffic. Table size is designed according to the actual requirements of customers.Load tonnage: 1-100 tons, lifting height: 1-20 meters.

Contact Now E-Mail Telephone WhatsApp

Product Details

Application:

Fixed scissor lift platform for up and down control, electric lifting, so that the aerial work is safer and more efficient. Equipment is widely used in production lines, warehouses, shopping malls, parking lots, families and other industries. According to the use of requirements, can be configured with ancillary devices, any combination, such as: fixed lift safety guards, electrical control mode, the form of the working platform, power form, etc.

Fixed Scissor Aerial Work Platform

Product Parameters:

Model	SJG1.0-4	SJG1.0-6	SJG1.0-8
Platform net lifting height (m)	4	6	8
Height of equipment itself (m)	0.55	0.7	0.85
Load capacity (kg)	1000	1000	1000
Collection length (m)	2.5	2.5	2.5
Collection width (m)	2	2	2
Collection height (m)	0.55	0.7	0.85
Table length (m)	2.5	2.5	2.5
Table width (m)	2	2	2
Guardrail height (m)	1	1	1
Voltage (V) AC/DC	380/12	380/12	380/12
Motor power (kW)	3	3	3
Ascending / descending speed m/ s	0.18/0.30	0.18/0.30	0.18/0.30
Weight of the whole machine (kg)	800	1100	1400

Model	SJG1.0-4	SJG1.0-6	SJG1.0-8
Platform net lifting height (m)	4	6	8
Height of equipment itself (m)	0.55	0.7	0.85
Load capacity (kg)	1000	1000	1000
Collection length (m)	2.5	2.5	2.5
Collection width (m)	2	2	2
Collection height (m)	0.55	0.7	0.85
Table length (m)	2.5	2.5	2.5
Table width (m)	2	2	2
Guardrail height (m)	1	1	1
Voltage (V) AC/DC	380/12	380/12	380/12
Motor power (kW)	3	3	3
Ascending / descending speed m/ s	0.18/0.30	0.18/0.30	0.18/0.30
Weight of the whole machine (kg)	800	1100	1400
